Hi, I'm Tim Carter from AskTheBuilder.com. It's a cold winter day, and I want to show you something
0:10
that's really pretty neat. If you remember, a couple of weeks ago we poured this great concrete
0:13
slab. Look at this. Yeah, here's the slab. And it's nice and hard. It's curing out really well
0:23
But I want to show you something. These were added later. These are concrete control joints
0:29
and what these are, the contractor came back and looked down here. See this line right here
0:35
This was not in here when the slab was poured. These were saw cut in later with a special
0:41
diamond saw that cuts a groove in the concrete. And you'll notice they were put here for a
0:47
reason. See that? That's an inside corner on the concrete foundation. That's exactly
0:53
where the slab wants to crack, right at this corner, and if you did not put in these two
0:59
saw joints, you'd probably get a very random squiggly crack that just went all the way
1:05
across the slab. And understand this about concrete. When you pour concrete and as it
1:14
cures and hardens, it shrinks. The water in the concrete leaves, some of it leaves the
1:20
concrete some of it goes into the chemical reaction hydration and this concrete shrinks It shrinks 1 16th of an inch for every 10 linear feet that you pour So that shrinkage creates tension where it tries to literally
1:37
rip the concrete apart. So, you need to saw cut in these concrete control joints after
1:43
the fact on these nice smooth slabs. Sometimes on sidewalks and driveways, they actually
1:48
have a nice tool that will cut that control joint in as the concrete is still in its plastic
1:54
or wet state. Understand this though, that joint needs to be at least, the depth of the
1:59
joint needs to be one fourth minimum the thickness of the slab, so if this is a four inch thick
2:05
slab, it means that saw cut line should be an inch deep, and many, many times you'll
2:11
notice that contractors actually don't cut the crack or the line that deep. So concrete
2:17
control joints. They're called control joints because they control where the slab is supposed
2:23
to crack. It doesn't always work that way, but that's what they're supposed to do. I'm Tim Carter
2:27
for AskTheBuilder.com. If you want to discover more home improvement tips, go to AskTheBuilder.com
